        Main Power Control Center

        Main Power Control Center
        Main Power Control Center
        Send Inquiry
        Product Code : 01
        Price And Quantity
        • Minimum Order Quantity
        • 1 Unit/Units
        • Price
        • 25000 INR
        Product Description

        Our enterprise is amongst one of the most reliable and trustworthy organizations, exclusively engaged in offering a wide range of Main Power Control Center. Our offered products are used to convert high voltage into less voltage as per the need of the clients. This Main Power Control Center distributes the power supply into various sub-distribution panels power control centers and feeder pillars. Our control centers are made available in different specifications as per the descriptions provided by the clients.

        Power Control Centre is a main power control panel which consists of feeder breakers and supply breakers, monitoring devices, control devices, switching devices, protection devices, instrumentation devices, etc. It is also known as Main Switchboard. It is mainly installed near power sources hence its fault level is high. It is designed to suit fault level of 50KA or 65 KA for 1 sec. Bus Bar system in Power Control Centers are designed to suit the fault level as well as temperature rise to 40°c above ambient. Ample space is provided for cable termination. Various protections viz short circuit, overload, earth fault, under voltage etc are provided to protect source and equipment.

        Technical Details:-

        CONSTRUCTION FIXED/DRAWOUT TYPE, FULLY COMPARTMENTALIZED.
        DESIGN THE PANEL IS DESIGNED FULLY DUST & VERMIN PROOF CONSIDERING ALL TECHNICAL PARAMETERS, EASY TO USE & MAINTAIN BY HIGHLY COMPETENT DESIGN ENGINEERS.
        PROTECTION CLASS IP42 / IP 54 / IP 55
        SHEET CRCA SHEET OF 1.63MM / 2.02MM / 2.5MM / 3.15MM as required. Modular construction with wide choice of compartment sizes. As standard 2.02MM Thick Sheet is used.
        SURFACE COATING ELECTROSTATICALLY APPLIED EPOXY POLYESTER POWDER COATING IS DONE AFTER PROPER SEVEN TANK CHEMICAL TREATMENT OF MINIMUM 80MICRONS THICKNESS WITH SIEMENS GREY COLOUR RAL 7032 AS STANDARD.
        RATED VOLTAGE 600 VOLT, AC, 50 HZ, 3 PHASE, 4WIRE
        RATED CURRENT UP TO 6000A MAIN BUS BAR
        SHORT CIRCUIT LEVEL STANDARD 50 KA 1 SEC
        OPTIONAL 65 KA 1 SEC
        BUS BAR E91 ELECTROLYTIC GRADE ALUMINIUM/COPPER BUS BAR IS USED
        BUSBAR SUPPORT SMC / DMC
        BUS BAR INSULATION BUS BARS ARE COVERED WITH COLOURED HEAT SHRINKABLE SLEEVES
        STANDARD IS 8623 DT
        CABLE CHAMBER THE CABLE CHAMBER CONSISTS OF AMPLE SPACE FOR TERMINATION OF CABLES WITH PROPER CABLE SUPPORTS AND VENTILATION SYSTEM FOR HEAT GENERATED IN CABLES
        CABLE ENTRY TOP / BOTTOM



        Trade Information
        • Supply Ability
        • 50 Per Month
        • Delivery Time
        • 2-4 Week
